| Copier Specifications |
| Copying process |
Electrostatic laser copy; Tandem; indirect |
| Toner system |
High-definition polymerised toner |
| Copy/print speed A4 mono (cpm) |
36 |
| Copy/print speed A4 colour (cpm) |
36 |
| Copy/print speed A3 mono (cpm) |
17 |
| Copy/print speed A3 colour (cpm) |
17 |
| Autoduplex speed A4 mono (cpm) |
36 |
| Autoduplex speed A4 colour (cpm) |
36 |
| 1st Copy/print time mono (sec) |
5.8 |
| 1st Copy/print time colour (sec) |
7.7 |
| Warm-up time (sec) |
Approx. 45 *
* Warm up time may vary depending on the operating environment and usage |
| Copy resolution (dpi) |
600 x 600 |
| Gradations |
256 gradations |
| Original format |
A5-A3 |
| Magnification |
25-400% in 0.1% steps; Autozooming |
| Copy functions |
Chapter, Cover and page insertion; Proof copy (print and screen); Adjustment test print; Digital art functions; Job setting memory; Poster Mode; Image repeat; Overlay; Watermark; Stamping; Copy Protection; Card shot |
| Printer Specifications |
| Print resolution (dpi) |
Equivalent to 1,800 x 600 |
| Controller CPU Type |
MPC8533 @ 1 GHz |
| Page description language |
PCL 6c (PCL 5c + XL3.0);
PostScript 3 (CPSI 3017) |
| Operating systems |
Windows 2000/XP/XP64
Windows VISTA 32/64
Windows DPWS support
Windows Server 2000/2003/2003×64/2008/2008×64
Macintosh 9.x/10.x
Unix/Linux/Citrix |
| Printer fonts |
80x PCL Latin; 137x PostScript 3 Emulation Latin |
| Print functions |
Direct print of PCL; PS; TIFF; XPS; PDF and Encrypted PDF files Mixmedia and mixplex; Job programming “Easy Set”; Overlay; Watermark; Copy Protection |
| Scanner Specifications |
| Scan speed colour (opm) |
up to 70 (300 dpi via DF) |
| Scan Speed mono (opm) |
up to 70 (300 dpi via DF) |
| Scan resolution (dpi) |
Max.: 600 x 600 |
| Scan modes |
Network TWAIN scan; scan-to-eMail (scan-to-Me); scan-to-FTP; Scan-to-SMB (scan-to-Home); scan-to-Box; scan-to-WebDAV; scan-to-DPWS; scan-to-USB |
| File formats |
JPEG; TIFF; PDF; Compact PDF; Encrypted PDF; Outline PDF, XPS; Compact XPS |
| Scan destinations |
2,100 (single + group); LDAP support |
| Scan functions |
Annotation (text/time/date) for PDF; up to 400 job programs |
| Fax Specifications |
| Fax standard |
Super G3 (optional) |
| Fax transmission |
Analogue; i-Fax; Colour i-Fax (RFC3949-C); IP-Fax |
| Fax resolution (dpi) |
Max.: 600 x 600 (ultra-fine) |
| Fax compression |
MH; MR; MMR; JBIG |
| Fax modem (Kbps) |
Up to 33.6 |
| Fax destinations |
2,100 (single + group) |
| Fax functions |
Polling; Time shift; PC-Fax; Receipt to confidential box; Receipt to eMail/FTP/SMB; up to 400 job programs |
| User box specification |
| Max. storable documents |
Up to 3,000 documents or 10,000 pages |
| Type of user boxes |
Public;
personal (with password or authentication);
group (with authentication) |
| Type of system boxes |
Secure print; encrypted PDF print; fax receiving; fax polling |
| User box functionality |
Reprint; combination; download; sending (email/FTP/SMB and Fax); copy box to box |
| System Specifications |
| System memory standard (MB) |
2,048 |
| System hard disc standard (GB) |
250 |
| Network protocols |
TCP/IP (IPv4 / IPv6); IPX/SPX; NetBEUI; AppleTalk (EtherTalk); SMB; LPD; IPP; SNMP; HTTP |
| Frame types |
Ethernet 802.2; Ethernet 802.3; Ethernet II; Ethernet SNAP |
| Automatic document feeder |
Up to 100 originals;
A6-A3; 35-210 g/m² |
| Paper size |
A6-A3 full bleed;
customised paper sizes;
banner paper max. 1,200 x 297 mm |
| Printable paper weight (g/m²) |
64 – 271 |
| Paper input capacity (sheets) |
Standard: 1,150
Max: 3,650 |
| Paper trays standard |
Tray 1: 500 sheets, A5-A3, 60-256 g/m²
Tray 2: 500 sheets, A5-A3+, 60-256 g/m²
Manual Bypass: 150 sheets A6 – A3+, custom sizes, banner 60 – 271 gsm |
| Paper trays optional |
Tray 3: 500 sheets A5 – A3 60 – 256 gsm
Tray 3 + 4: 2 x 500 sheets A5 – A3 60 – 256 gsm
Large Capacity Cabinet: 2,500 sheets A4 60 – 256 gsm |
| Automatic duplexing |
A5-A3+; 64-256 g/m² |
| Finishing modes (optional) |
Offset; group; sort; staple; punch; centre-fold; booklet |
| Output capacity (w. finisher) |
Max.: 3,200 sheets |
| Output capacity (w/o finisher) |
Max.: 250 sheets |
| Stapling |
50 sheets or 48 sheets + 2 cover sheets (up to 209 g/m²) |
| Stapling output capacity |
Max. 1,000 sheets |
| Booklet |
15 sheets or 14 sheets + 1 cover sheet (up to 209 g/m²) |
| Booklet output capacity |
75 sheets |
| Copy/print volume recommended (monthly) |
40,000 pages |
| Copy/print volume max. (monthly) |
60,000 pages |
| Toner lifetime Black |
29,000 |
| Toner lifetime CMY |
26,000 |
| Developer lifetime Black |
570,000 |
| Developer lifetime CMY |
115,000 |
| Drum lifetime Black |
120,000 |
| Drum lifetime CMY |
90,000 |
| Power consumption |
Less than 1.5 KW |
| System dimensions (WxDxH, mm) |
643 x 842 x 770 |
| System weight (kg) |
Approx. 98 |
| System Features |
| Security |
ISO15408 EAL3 (in evaluation)
IP filtering and port blocking
SSL2, SSL3 and TSL1.0 network communication
IPsec support
IEEE 802.1x support
User authentication, authentication log
Secure Print
Hard disk overwrite (8 standard types)
Hard disk data encryption (AES 128)
Memory data auto deletion
Confidential fax receipt
Print user data encryption
Copy Guard and Password Copy |
| Accounting |
Up to 1,000 User Accounts
Active Directory support
(user name + password + email + smb folder)
User function access definition
Biometric Authentication (finger vein) optional
IC-Card Authentication (IC-Card reader) optional |
| Software |
PageScope Net Care Device Manger
PageScope Data Administrator
PageScope Box Operator
PageScope Direct Print
Print Status Notifier
Driver Packaging Utility
Log Management Utility |
